MJE15029
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS PNP 120V 8A TO220AB
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet MJE15029 Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Transistor Type:PNP
- Current - Collector (Ic) (Max):8 A
- Voltage - Collector Emitter Breakdown (Max):120 V
- Vce Saturation (Max) @ Ib, Ic:500mV @ 100mA, 1A
- Current - Collector Cutoff (Max):100µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:20 @ 4A, 2V
- Power - Max:50 W
- Frequency - Transition:30MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220AB
