2N5401RLRAG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS PNP 150V 0.6A TO92
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2N5401RLRAG Datasheet
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Transistor Type:PNP
- Current - Collector (Ic) (Max):600 mA
- Voltage - Collector Emitter Breakdown (Max):150 V
- Vce Saturation (Max) @ Ib, Ic:500mV @ 5mA, 50mA
- Current - Collector Cutoff (Max):50nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:60 @ 10mA, 5V
- Power - Max:625 mW
- Frequency - Transition:300MHz
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Supplier Device Package:TO-92-3
