2SB1203T-H
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS PNP 50V 5A TP
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2SB1203T-H Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:PNP
- Current - Collector (Ic) (Max):5 A
- Voltage - Collector Emitter Breakdown (Max):50 V
- Vce Saturation (Max) @ Ib, Ic:550mV @ 150mA, 3A
- Current - Collector Cutoff (Max):1µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:200 @ 500mA, 2V
- Power - Max:1 W
- Frequency - Transition:130MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
- Supplier Device Package:TP
