514-AG12D-LF
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN IC DIP SOCKET 14POS TIN
- CategorySockets for ICs, Transistors
- Datasheet 514-AG12D-LF Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$2.69229
- 1,360$2.69229
Quote It
Technical Details
- Series:500
- Package:Tube
- Part Status:Active
- Type:DIP, 0.3" (7.62mm) Row Spacing
- Number of Positions or Pins (Grid):14 (2 x 7)
- Pitch - Mating:0.100" (2.54mm)
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Material - Mating:Beryllium Copper
- Mounting Type:Through Hole
- Features:Closed Frame
- Termination:Solder
- Pitch - Post:0.100" (2.54mm)
- Contact Finish - Post:Tin
- Contact Finish Thickness - Post:-
- Contact Material - Post:Beryllium Copper
- Housing Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
- Operating Temperature:-55°C ~ 105°C
