09-0503-20
Aries Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN SOCKET SIP 9POS GOLD
- CategorySockets for ICs, Transistors
- Datasheet 09-0503-20 Datasheet
-
ECAD Model
- Share
In Stock: 150
Can ship immediately
Pricing:
- 1$4.09185
- 27$4.09185
Quote It
Technical Details
- Series:0503
- Package:Bulk
- Part Status:Active
- Type:SIP
- Number of Positions or Pins (Grid):9 (1 x 9)
- Pitch - Mating:0.100" (2.54mm)
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:30.0µin (0.76µm)
- Contact Material - Mating:Beryllium Copper
- Mounting Type:Through Hole
- Features:-
- Termination:Wire Wrap
- Pitch - Post:0.100" (2.54mm)
- Contact Finish - Post:Tin
- Contact Finish Thickness - Post:200.0µin (5.08µm)
- Contact Material - Post:Brass
- Housing Material:Polyamide (PA), Nylon, Glass Filled
- Operating Temperature:-
