20-6513-11
Aries Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN IC DIP SOCKET 20POS GOLD
- CategorySockets for ICs, Transistors
- Datasheet 20-6513-11 Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$4.13593
- 27$4.13593
Quote It
Technical Details
- Series:Lo-PRO®file, 513
- Package:Bulk
- Part Status:Active
- Type:DIP, 0.6" (15.24mm) Row Spacing
- Number of Positions or Pins (Grid):20 (2 x 10)
- Pitch - Mating:0.100" (2.54mm)
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:10.0µin (0.25µm)
- Contact Material - Mating:Beryllium Copper
- Mounting Type:Through Hole
- Features:Closed Frame
- Termination:Solder
- Pitch - Post:0.100" (2.54mm)
- Contact Finish - Post:Gold
- Contact Finish Thickness - Post:10.0µin (0.25µm)
- Contact Material - Post:Brass
- Housing Material:Polyamide (PA46), Nylon 4/6, Glass Filled
- Operating Temperature:-55°C ~ 105°C
