10-28440-10

Technical Details

• Series:8
• Package:Bulk
• Part Status:Active
• Type:DIP, 0.2" (5.08mm) Row Spacing
• Number of Positions or Pins (Grid):10 (2 x 5)
• Pitch - Mating:0.100" (2.54mm)
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:200.0µin (5.08µm)
• Contact Material - Mating:Phosphor Bronze

• Mounting Type:Through Hole
• Features:Closed Frame, Elevated
• Termination:Solder
• Pitch - Post:0.100" (2.54mm)
• Contact Finish - Post:Tin
• Contact Finish Thickness - Post:200.0µin (5.08µm)
• Contact Material - Post:Phosphor Bronze
• Housing Material:Polyamide (PA46), Nylon 4/6, Glass Filled
• Operating Temperature:-55°C ~ 105°C
