14-822-90T
Aries Electronics, Inc.- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN IC DIP SOCKET 14POS TIN
- CategorySockets for ICs, Transistors
- Datasheet 14-822-90T Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$7.59
- 16$7.26
Quote It
Technical Details
- Series:Vertisockets™ 800
- Package:Bulk
- Part Status:Active
- Type:DIP, 0.3" (7.62mm) Row Spacing
- Number of Positions or Pins (Grid):14 (2 x 7)
- Pitch - Mating:0.100" (2.54mm)
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:200.0µin (5.08µm)
- Contact Material - Mating:Phosphor Bronze
- Mounting Type:Through Hole, Right Angle, Horizontal
- Features:Closed Frame
- Termination:Solder
- Pitch - Post:0.100" (2.54mm)
- Contact Finish - Post:Tin
- Contact Finish Thickness - Post:200.0µin (5.08µm)
- Contact Material - Post:Phosphor Bronze
- Housing Material:Polyamide (PA46), Nylon 4/6
- Operating Temperature:-
