115-47-320-41-003000
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN IC DIP SOCKET 20POS GOLD
- CategorySockets for ICs, Transistors
- Datasheet 115-47-320-41-003000 Datasheet
-
ECAD Model
- Share
In Stock: 124
Can ship immediately
Pricing:
- 1$12.40733
- 20$11.26851
- 40$10.57946
- 60$10.11933
- 100$9.65911
- 260$8.73937
- 500$8.04934
- 1,000$6.89936
- 2,500$6.4394
Quote It
Technical Details
- Series:115
- Package:Tube
- Part Status:Active
- Type:DIP, 0.3" (7.62mm) Row Spacing
- Number of Positions or Pins (Grid):20 (2 x 10)
- Pitch - Mating:0.100" (2.54mm)
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:Flash
- Contact Material - Mating:Beryllium Copper
- Mounting Type:Through Hole
- Features:Open Frame
- Termination:Solder
- Pitch - Post:0.100" (2.54mm)
- Contact Finish - Post:Tin
- Contact Finish Thickness - Post:200.0µin (5.08µm)
- Contact Material - Post:Brass Alloy
- Housing Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
- Operating Temperature:-55°C ~ 125°C
