CHM-6-30-95-9-AA00-F2-2
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CHM6 WARM WHITE RECT
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CHM-6-30-95-9-AA00-F2-2 Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$1.6422
- 2,400$1.6422
Quote It
Technical Details
- Series:CHM-6
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Rectangle
- Luminous Flux @ Current/Temperature:485lm (Typ)
- Current - Test:640mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):9V
- Lumens/Watt @ Current - Test:84 lm/W
- Current - Max:1.28A
- CRI (Color Rendering Index):95
- Viewing Angle:120°
- Features:-
- Size / Dimension:12.00mm L x 13.00mm W
- Height:1.37mm
- Light Emitting Surface (LES):6.30mm Dia
- Lens Type:Flat
