CXM-9-40-95-36-AA00-F2-3
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXM-9-40-95-36-AA00-F2-3 Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$1.8354
- 1,800$1.8354
Quote It
Technical Details
- Series:CXM-9
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Neutral
- CCT (K):4000K 3-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:900lm (Typ)
- Current - Test:240mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):35V
- Lumens/Watt @ Current - Test:107 lm/W
- Current - Max:530mA
- CRI (Color Rendering Index):95
- Viewing Angle:120°
- Features:With Connector
- Size / Dimension:15.00mm L x 15.00mm W
- Height:1.37mm
- Light Emitting Surface (LES):8.90mm Dia
- Lens Type:Flat
