SPHWHAHDND27YZV2D3
Samsung Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB D 3000K SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet SPHWHAHDND27YZV2D3 Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$1.8816
- 1,000$1.8816
Quote It
Technical Details
- Series:COB D Gen3
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:1661lm (Typ)
- Current - Test:360mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):34V
- Lumens/Watt @ Current - Test:136 lm/W
- Current - Max:920mA
- CRI (Color Rendering Index):90
- Viewing Angle:115°
- Features:-
- Size / Dimension:13.50mm L x 13.50mm W
- Height:1.50mm
- Light Emitting Surface (LES):9.80mm Dia
- Lens Type:Flat
