SPHWHAHDNM251ZP3DB
Samsung Semiconductor- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB WHT LC080D 6500K 80CRI
- CategoryLED Lighting - COBs, Engines, Modules, Strips
-
ECAD Model
- Share
In Stock: 105
Can ship immediately
Pricing:
- 1$8.04481
Quote It
Technical Details
- Series:COB D Gen2
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Cool
- CCT (K):6500K 3-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:13121lm (Typ)
- Current - Test:1.62A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):51.1V
- Lumens/Watt @ Current - Test:159 lm/W
- Current - Max:3.24A
- CRI (Color Rendering Index):80
- Viewing Angle:115°
- Features:-
- Size / Dimension:28.00mm L x 28.00mm W
- Height:1.50mm
- Light Emitting Surface (LES):22.00mm Dia
- Lens Type:Flat
