SPHWHAHDNL251ZT2D3
Samsung Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB D 4000K SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet SPHWHAHDNL251ZT2D3 Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$8.07555
- 320$8.07555
Quote It
Technical Details
- Series:COB D Gen3
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Neutral
- CCT (K):4000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:9253lm (Typ)
- Current - Test:1.08A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):51V
- Lumens/Watt @ Current - Test:168 lm/W
- Current - Max:2.76A
- CRI (Color Rendering Index):80
- Viewing Angle:115°
- Features:-
- Size / Dimension:28.00mm L x 28.00mm W
- Height:1.50mm
- Light Emitting Surface (LES):22.00mm Dia
- Lens Type:Flat
