CLU026-1204C1-303H7G5
Citizen Electronics Co., Ltd.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOB LED 3000K 97CRI 1255LM
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CLU026-1204C1-303H7G5 Datasheet
-
ECAD Model
- Share
In Stock: 150
Can ship immediately
Pricing:
- 1$8.15667
- 54$7.695
Quote It
Technical Details
- Series:CLU026
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 3-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:1255lm (Typ)
- Current - Test:360mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):34.6V
- Lumens/Watt @ Current - Test:101 lm/W
- Current - Max:920mA
- CRI (Color Rendering Index):97 (Typ)
- Viewing Angle:-
- Features:-
- Size / Dimension:13.50mm L x 13.50mm W
- Height:1.40mm
- Light Emitting Surface (LES):9.80mm Dia
- Lens Type:Flat
