SPHWW1HDNE27YHW24K
Samsung Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB LC040B 2700K SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet SPHWW1HDNE27YHW24K Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$8.31144
- 320$8.31144
Quote It
Technical Details
- Series:LC040B Gen2
- Package:Tray
- Part Status:Not For New Designs
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):2700K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:4516lm (4126lm ~ 4906lm)
- Current - Test:1.08A
- Temperature - Test:25°C
- Voltage - Forward (Vf) (Typ):35.5V
- Lumens/Watt @ Current - Test:118 lm/W
- Current - Max:1.9A
- CRI (Color Rendering Index):90
- Viewing Angle:115°
- Features:-
- Size / Dimension:21.50mm L x 21.50mm W
- Height:1.50mm
- Light Emitting Surface (LES):17.00mm Dia
- Lens Type:Flat
