CHM-18-27-80-36-AA00-F2-3

Luminus Devices
In Stock: 191

Can ship immediately

Pricing:
  • 1$8.372
  • 900$8.372

Quote It

Technical Details

  • Series:CHM-18
  • Package:Tray
  • Part Status:Active
  • Type:Chip On Board (COB)
  • Color:White, Warm
  • CCT (K):2700K 3-Step MacAdam Ellipse
  • Wavelength:-
  • Configuration:Square
  • Luminous Flux @ Current/Temperature:4430lm (Typ)
  • Current - Test:1.2A
  • Temperature - Test:85°C



  • Voltage - Forward (Vf) (Typ):35V
  • Lumens/Watt @ Current - Test:115 lm/W
  • Current - Max:2.4A
  • CRI (Color Rendering Index):80
  • Viewing Angle:120°
  • Features:-
  • Size / Dimension:21.50mm L x 21.50mm W
  • Height:1.37mm
  • Light Emitting Surface (LES):17.50mm Dia
  • Lens Type:Flat
