CXA1830-0000-000N0YR227F
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CXA1830 WARM WHT SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXA1830-0000-000N0YR227F Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$8.5
- 100$8.5
Quote It
Technical Details
- Series:XLamp® CXA1830
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):2700K 4-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:2510lm (2420lm ~ 2600lm)
- Current - Test:800mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):37V
- Lumens/Watt @ Current - Test:85 lm/W
- Current - Max:1.4A
- CRI (Color Rendering Index):93
- Viewing Angle:115°
- Features:-
- Size / Dimension:17.85mm L x 17.85mm W
- Height:1.70mm
- Light Emitting Surface (LES):14.00mm Dia
- Lens Type:Flat
