BXRC-30E4000-B-72
Bridgelux, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB VERO 18 3000K ROUND
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet BXRC-30E4000-B-72 Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$8.64
- 100$8.64
Quote It
Technical Details
- Series:Gen 7 Vero® 18 Array
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Round
- Luminous Flux @ Current/Temperature:4394lm (Typ)
- Current - Test:900mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):34.1V
- Lumens/Watt @ Current - Test:143 lm/W
- Current - Max:1.8A
- CRI (Color Rendering Index):80
- Viewing Angle:-
- Features:With Connector
- Size / Dimension:36.20mm Dia
- Height:1.90mm
- Light Emitting Surface (LES):18.40mm Dia
- Lens Type:Flat
