SPHWHAHDNM271ZT2D2
Samsung Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB LC080D 4000K SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet SPHWHAHDNM271ZT2D2 Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$10.26615
- 160$10.26615
Quote It
Technical Details
- Series:LC080D Gen2
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Neutral
- CCT (K):4000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:11247lm (Typ)
- Current - Test:1.62A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):52V
- Lumens/Watt @ Current - Test:134 lm/W
- Current - Max:4.14A
- CRI (Color Rendering Index):90
- Viewing Angle:115°
- Features:-
- Size / Dimension:28.00mm L x 28.00mm W
- Height:1.50mm
- Light Emitting Surface (LES):22.00mm Dia
- Lens Type:Flat
