CHM-22-50-70-36-AC00-F2-5
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CHM22 COOL WHITE SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CHM-22-50-70-36-AC00-F2-5 Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$12.67875
- 400$12.29063
Quote It
Technical Details
- Series:CHM-22
- Package:Tray
- Part Status:Not For New Designs
- Type:Chip On Board (COB)
- Color:White, Cool
- CCT (K):5000K 5-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:8725lm (Typ)
- Current - Test:1.92A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):35V
- Lumens/Watt @ Current - Test:130 lm/W
- Current - Max:3.84A
- CRI (Color Rendering Index):70
- Viewing Angle:120°
- Features:-
- Size / Dimension:28.00mm L x 28.00mm W
- Height:1.37mm
- Light Emitting Surface (LES):22.00mm Dia
- Lens Type:Flat
