L235-5770AMLF5WAD0
Philips (LUMILEDS)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED 3535L 5700K 70CRI COOL WHITE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet L235-5770AMLF5WAD0 Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$12.904
- 500$11.64026
Quote It
Technical Details
- Series:LUXEON XF-3535L
- Package:Strip
- Part Status:Active
- Type:LED Module
- Color:White, Cool
- CCT (K):5700K
- Wavelength:-
- Configuration:Linear Light Strip, Flexible
- Luminous Flux @ Current/Temperature:2632lm (Typ)
- Current - Test:800mA
- Temperature - Test:25°C
- Voltage - Forward (Vf) (Typ):21V
- Lumens/Watt @ Current - Test:157 lm/W
- Current - Max:1.2A
- CRI (Color Rendering Index):70
- Viewing Angle:-
- Features:-
- Size / Dimension:525.40mm L x 5.25mm W
- Height:1.23mm
- Light Emitting Surface (LES):-
- Lens Type:Flat
