CXA1520-0000-000N00P250F
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CXA1520 COOL WHT SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXA1520-0000-000N00P250F Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$13.82
- 10$13.12702
Quote It
Technical Details
- Series:XLamp® CXA1520
- Package:Tray
- Part Status:Obsolete
- Type:Chip On Board (COB)
- Color:White, Cool
- CCT (K):5000K 4-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:1898lm (1830lm ~ 1965lm)
- Current - Test:500mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):35V
- Lumens/Watt @ Current - Test:108 lm/W
- Current - Max:900mA
- CRI (Color Rendering Index):70
- Viewing Angle:115°
- Features:-
- Size / Dimension:15.85mm L x 15.85mm W
- Height:1.55mm
- Light Emitting Surface (LES):8.90mm Dia
- Lens Type:Flat
