CMA2550-0000-000N0H0AL7B
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionXLAMP CMA LIGHT EMITTING DIODE W
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CMA2550-0000-000N0H0AL7B Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$16.66
- 100$16.66
Quote It
Technical Details
- Series:XLamp® CMA2550
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:6850lm (Typ)
- Current - Test:1.4A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):34V
- Lumens/Watt @ Current - Test:144 lm/W
- Current - Max:3.3A
- CRI (Color Rendering Index):80
- Viewing Angle:115°
- Features:-
- Size / Dimension:23.85mm L x 23.85mm W
- Height:1.70mm
- Light Emitting Surface (LES):19.00mm Dia
- Lens Type:Flat
