CXA3590-0000-000R0UZ465F
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CXA3590 COOL WHT SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXA3590-0000-000R0UZ465F Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$49.7866
- 50$49.7866
Quote It
Technical Details
- Series:XLamp® CXA3590
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Cool
- CCT (K):6500K 4-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:8223lm (7945lm ~ 8500lm)
- Current - Test:1.2A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):77V
- Lumens/Watt @ Current - Test:89 lm/W
- Current - Max:1.8A
- CRI (Color Rendering Index):90
- Viewing Angle:115°
- Features:-
- Size / Dimension:34.85mm L x 34.85mm W
- Height:1.70mm
- Light Emitting Surface (LES):30.00mm Dia
- Lens Type:Flat
