CXB3590-0000-000R0HCD30H
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CXB3590 WARM WHT SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXB3590-0000-000R0HCD30H Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
- 1$52.334
- 50$52.334
Quote It
Technical Details
- Series:Xlamp® CXB3590
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:12500lm (12000lm ~ 13000lm)
- Current - Test:1.2A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):72V
- Lumens/Watt @ Current - Test:145 lm/W
- Current - Max:1.8A
- CRI (Color Rendering Index):80
- Viewing Angle:115°
- Features:-
- Size / Dimension:34.85mm L x 34.85mm W
- Height:1.70mm
- Light Emitting Surface (LES):30.00mm Dia
- Lens Type:Flat
