CBT-140-WCS-L16-UA122
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBIG CHIP LED COOL WHITE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CBT-140-WCS-L16-UA122 Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$106.7976
- 50$106.7976
Quote It
Technical Details
- Series:CBT-140
- Package:Tray
- Part Status:Active
- Type:LED Module
- Color:White, Cool
- CCT (K):6020K ~ 7040K
- Wavelength:-
- Configuration:Rectangle
- Luminous Flux @ Current/Temperature:3818lm (3680lm ~ 3955lm)
- Current - Test:21A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):3.6V
- Lumens/Watt @ Current - Test:50 lm/W
- Current - Max:28A
- CRI (Color Rendering Index):75 (Typ)
- Viewing Angle:-
- Features:With Connector
- Size / Dimension:28.00mm L x 42.00mm W
- Height:5.70mm
- Light Emitting Surface (LES):4.25mm Dia
- Lens Type:Flat
