CXA2011-0000-000P0UG030H
Cree
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED XLAMP CXA WHT 3000K SCREW MT
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXA2011-0000-000P0UG030H Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:XLamp® CXA2011
- Package:Tube
- Part Status:Obsolete
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:840lm (780lm ~ 900lm)
- Current - Test:270mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):40V
- Lumens/Watt @ Current - Test:78 lm/W
- Current - Max:1A
- CRI (Color Rendering Index):90
- Viewing Angle:120°
- Features:-
- Size / Dimension:22.00mm L x 22.00mm W
- Height:2.28mm
- Light Emitting Surface (LES):-
- Lens Type:Flat
