CBT-140-WDH-C15-QB220
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBIG CHIP LED DAY WHITE 2420LM
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CBT-140-WDH-C15-QB220 Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:CBT-140
- Package:-
- Part Status:Obsolete
- Type:LED Module
- Color:-
- CCT (K):-
- Wavelength:-
- Configuration:Rectangle
- Luminous Flux @ Current/Temperature:2340lm (2260lm ~ 2420lm)
- Current - Test:21A
- Temperature - Test:40°C
- Voltage - Forward (Vf) (Typ):3.6V
- Lumens/Watt @ Current - Test:31 lm/W
- Current - Max:28A
- CRI (Color Rendering Index):92 (Typ)
- Viewing Angle:-
- Features:With Connector
- Size / Dimension:28.00mm L x 42.00mm W
- Height:5.70mm
- Light Emitting Surface (LES):4.25mm Dia
- Lens Type:Flat
