SBR-160-RGBW-R41-RE102
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBIG CHIP LED HB MODULE RGB WHT
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet SBR-160-RGBW-R41-RE102 Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SBR-160
- Package:-
- Part Status:Obsolete
- Type:LED Module
- Color:Red, Green, Blue, White - Cool (RGBW)
- CCT (K):6500K
- Wavelength:623nm Red, 530nm Green, 458nm Blue
- Configuration:Square
- Luminous Flux @ Current/Temperature:320lm (Typ) Red, 820lm (Typ) Green, 150lm (Typ) Blue, 730lm (Typ) White
- Current - Test:4A Red, 4A Green, 4A Blue, 4A White
- Temperature - Test:25°C
- Voltage - Forward (Vf) (Typ):2.6V Red, 4.6V Green, 3.8V Blue, 3.8V White
- Lumens/Watt @ Current - Test:31 lm/W Red, 45 lm/W Green, 10 lm/W Blue, 48 lm/W White
- Current - Max:4A Red, 4A Green, 4A Blue, 4A White
- CRI (Color Rendering Index):-
- Viewing Angle:-
- Features:With Connector
- Size / Dimension:36.00mm L x 36.00mm W
- Height:8.72mm
- Light Emitting Surface (LES):-
- Lens Type:Flat
