CSM-360-WDLS-D22-GT150
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBIG CHIP LED HB MOD WHITE 2100LM
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CSM-360-WDLS-D22-GT150 Datasheet
-
ECAD Model
- Share
In Stock: 102
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:CSM-360
- Package:-
- Part Status:Obsolete
- Type:LED Module
- Color:White, Cool
- CCT (K):5700K
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:2300lm (2100lm ~ 2500lm)
- Current - Test:3.15A
- Temperature - Test:25°C
- Voltage - Forward (Vf) (Typ):14.15V
- Lumens/Watt @ Current - Test:52 lm/W
- Current - Max:6.3A
- CRI (Color Rendering Index):70 (Typ)
- Viewing Angle:-
- Features:With Connector
- Size / Dimension:51.00mm L x 36.00mm W
- Height:12.20mm
- Light Emitting Surface (LES):16.00mm Dia
- Lens Type:Domed
