BXRC-27H1000-B-03
Bridgelux, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB ULTRAVERO10 WARMWHT STAR
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet BXRC-27H1000-B-03 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Décor Series™ Ultra Vero® 10
- Package:Tray
- Part Status:Obsolete
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):2700K 3-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Starboard
- Luminous Flux @ Current/Temperature:690lm (Typ)
- Current - Test:350mA
- Temperature - Test:25°C
- Voltage - Forward (Vf) (Typ):26.7V
- Lumens/Watt @ Current - Test:74 lm/W
- Current - Max:700mA
- CRI (Color Rendering Index):97
- Viewing Angle:120°
- Features:-
- Size / Dimension:20.00mm L x 20.00mm W
- Height:1.90mm
- Light Emitting Surface (LES):9.90mm Dia
- Lens Type:Flat
