GW5SMC27P05

Technical Details

• Series:Petite Zenigata
• Package:Tray
• Part Status:Obsolete
• Type:Chip On Board (COB)
• Color:White, Warm
• CCT (K):2700K
• Wavelength:-
• Configuration:Rectangle
• Luminous Flux @ Current/Temperature:280lm (Typ)
• Current - Test:400mA
• Temperature - Test:25°C

• Voltage - Forward (Vf) (Typ):9.8V
• Lumens/Watt @ Current - Test:71 lm/W
• Current - Max:460mA
• CRI (Color Rendering Index):80
• Viewing Angle:-
• Features:-
• Size / Dimension:8.00mm L x 12.00mm W
• Height:1.80mm
• Light Emitting Surface (LES):-
• Lens Type:Flat
