BXRC-27G1000-B-02
Bridgelux, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED ARRAY 4000LM WARM WHITE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet BXRC-27G1000-B-02 Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Vero® 10 Array
- Package:Tray
- Part Status:Obsolete
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):2700K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Starboard
- Luminous Flux @ Current/Temperature:755lm (Typ)
- Current - Test:350mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):24.9V
- Lumens/Watt @ Current - Test:87 lm/W
- Current - Max:700mA
- CRI (Color Rendering Index):90
- Viewing Angle:120°
- Features:With Connector
- Size / Dimension:20.00mm Dia
- Height:1.90mm
- Light Emitting Surface (LES):9.90mm Dia
- Lens Type:Flat
