S4WM-1566658036-0D000G3S-00001

Technical Details

• Series:MJT COB
• Package:Tray
• Part Status:Obsolete
• Type:Chip On Board (COB)
• Color:White, Cool
• CCT (K):6500K 3-Step MacAdam Ellipse
• Wavelength:-
• Configuration:Square
• Luminous Flux @ Current/Temperature:4740lm (Typ)
• Current - Test:900mA
• Temperature - Test:85°C

• Voltage - Forward (Vf) (Typ):34.4V
• Lumens/Watt @ Current - Test:153 lm/W
• Current - Max:2.25A
• CRI (Color Rendering Index):80
• Viewing Angle:118°
• Features:-
• Size / Dimension:19.00mm L x 19.00mm W
• Height:1.45mm
• Light Emitting Surface (LES):14.50mm Dia
• Lens Type:Flat
