AVM35059-A
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 5A 125V
- CategorySnap Action, Limit Switches
- Datasheet AVM35059-A Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$1.77
- 10$1.66886
- 25$1.6021
- 50$1.53535
- 100$1.46859
- 300$1.1682
- 500$1.06807
- 1,000$1.03469
- 5,000$0.93456
Quote It
Technical Details
- Series:AVM3
- Package:Tray
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):5A (AC/DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Through Hole
- Termination Style:PC Pin
- Ingress Protection:-
- Features:-
- Operating Force:150gf
- Release Force:20gf
- Pretravel:0.024" (0.6mm)
- Differential Travel:0.004" (0.1mm)
- Overtravel:0.015" (0.4mm)
- Operating Temperature:-25°C ~ 85°C
