- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 15A 125V
- CategorySnap Action, Limit Switches
- Datasheet Z-15GW Datasheet
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
- 1$19.42
- 10$15.05811
- 25$14.26556
- 50$13.47301
- 100$12.28428
- 250$11.49172
- 500$11.09547
Quote It
Technical Details
- Series:Z
- Package:Tray
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):15A (AC), 6A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Lever, Straight
- Mounting Type:Chassis Mount
- Termination Style:Solder Lug
- Ingress Protection:IP00
- Features:-
- Operating Force:70gf
- Release Force:14gf
- Pretravel:-
- Differential Travel:0.050" (1.3mm)
- Overtravel:0.219" (5.6mm)
- Operating Temperature:-25°C ~ 80°C
