- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 15A 125V
- CategorySnap Action, Limit Switches
- Datasheet Z-15EWR Datasheet
-
ECAD Model
- Share
In Stock: 196
Can ship immediately
Pricing:
- 1$36.19
- 10$27.14517
- 25$24.88332
- 50$23.375
- 100$21.86699
- 250$21.11298
- 500$20.35894
Quote It
Technical Details
- Series:Z
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-On
- Current Rating (Amps):15A (AC/DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Lever, Straight
- Mounting Type:Chassis Mount
- Termination Style:Solder Lug
- Ingress Protection:IP00
- Features:Reset Plunger on Bottom
- Operating Force:55gf
- Release Force:300gf
- Pretravel:-
- Differential Travel:-
- Overtravel:0.219" (5.6mm)
- Operating Temperature:-25°C ~ 80°C
