- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 15A 125V
- CategorySnap Action, Limit Switches
- Datasheet ZE-Q-2G Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
- 1$76.86
- 10$67.2525
- 25$61.488
- 50$57.645
- 100$54.76275
Quote It
Technical Details
- Series:ZE
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):15A (AC), 500mA (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:125 V
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Chassis Mount
- Termination Style:Screw Terminal
- Ingress Protection:IP60 - Dust Tight
- Features:-
- Operating Force:250 ~ 350gf
- Release Force:114gf
- Pretravel:0.015" (0.4mm)
- Differential Travel:0.002" (0.05mm)
- Overtravel:0.217" (5.5mm)
- Operating Temperature:-10°C ~ 80°C
