SS-01GL-E-2D
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP SPST-NC 100MA 125V
- CategorySnap Action, Limit Switches
- Datasheet SS-01GL-E-2D Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$2.13
- 10$1.96739
- 25$1.84508
- 50$1.80386
- 100$1.435
- 250$1.35299
- 500$1.27097
- 1,000$1.18898
- 5,000$1.10697
Quote It
Technical Details
- Series:SS
- Package:Bulk
- Part Status:Active
- Circuit:SPST-NC
- Switch Function:On-Mom
- Current Rating (Amps):100mA (AC/DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Lever, Straight
- Mounting Type:Through Hole
- Termination Style:PC Pin
- Ingress Protection:IP40
- Features:-
- Operating Force:8.158gf
- Release Force:1.020gf
- Pretravel:-
- Differential Travel:0.031" (0.8mm)
- Overtravel:0.047" (1.2mm)
- Operating Temperature:-25°C ~ 85°C
