D3V-11G4M-2C24-K
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACT SPST-NC 11A 250V
- CategorySnap Action, Limit Switches
- Datasheet D3V-11G4M-2C24-K Datasheet
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
- 1$2.1509
- 10$1.98746
- 25$1.86288
- 50$1.82156
- 100$1.44889
- 250$1.36612
- 500$1.28334
- 1,000$1.20054
- 5,000$1.11774
Quote It
Technical Details
- Series:D3V
- Package:Bulk
- Part Status:Active
- Circuit:SPST-NC
- Switch Function:On-Mom
- Current Rating (Amps):11A (AC), 6A (DC)
- Voltage Rating - AC:250 V
- Voltage Rating - DC:30 V
- Actuator Type:Lever, Simulated Roller
- Mounting Type:Chassis Mount
- Termination Style:Quick Connect - 0.187" (4.7mm)
- Ingress Protection:IP40
- Features:-
- Operating Force:60gf
- Release Force:6.118gf
- Pretravel:0.157" (4.0mm)
- Differential Travel:0.031" (0.8mm)
- Overtravel:0.062" (1.6mm)
- Operating Temperature:-25°C ~ 105°C
