D3V16G22C26K
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACT SPST-NC 16A 250V
- CategorySnap Action, Limit Switches
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$2.5421
- 100$2.2212
Quote It
Technical Details
- Series:D3V
- Package:Bulk
- Part Status:Active
- Circuit:SPST-NC
- Switch Function:On-Mom
- Current Rating (Amps):16A (AC), 10A (DC)
- Voltage Rating - AC:250 V
- Voltage Rating - DC:30 V
- Actuator Type:Lever, Straight
- Mounting Type:Chassis Mount
- Termination Style:Quick Connect - 0.187" (4.7mm)
- Ingress Protection:IP40
- Features:-
- Operating Force:250gf
- Release Force:25gf
- Pretravel:0.157" (4.0mm)
- Differential Travel:0.031" (0.8mm)
- Overtravel:0.062" (1.6mm)
- Operating Temperature:-25°C ~ 105°C
