VM3SAQF3003L01
CIT Relay and Switch
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIP67 SNAP ACTION SWITCH, SPST N.
- CategorySnap Action, Limit Switches
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$12.835
Quote It
Technical Details
- Series:VM3S
- Package:Box
- Part Status:Active
- Circuit:SPST-NO
- Switch Function:Off-Mom
- Current Rating (Amps):10A (AC), 6A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:36 V
- Actuator Type:Lever, Roller
- Mounting Type:Chassis Mount
- Termination Style:Wire Leads
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Features:-
- Operating Force:210gf
- Release Force:100gf
- Pretravel:0.118" (3.0mm)
- Differential Travel:0.050" (1.3mm)
- Overtravel:0.031" (0.8mm)
- Operating Temperature:-40°C ~ 120°C
