- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 1A 125V
- CategorySnap Action, Limit Switches
- Datasheet 11SM23-H4 Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$13.2331
- 100$13.2331
Quote It
Technical Details
- Series:SM
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):1A (AC/DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Chassis Mount
- Termination Style:Solder, Quick Connect - 0.110" (2.8mm)
- Ingress Protection:-
- Features:-
- Operating Force:141gf
- Release Force:28gf
- Pretravel:0.020" (0.5mm)
- Differential Travel:0.004" (0.1mm)
- Overtravel:0.005" (0.13mm)
- Operating Temperature:-55°C ~ 125°C
