- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 20A 125V
- CategorySnap Action, Limit Switches
- Datasheet BA-2RB-A4 Datasheet
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
- 1$17.1938
- 50$17.1938
Quote It
Technical Details
- Series:BA
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):20A (AC), 500mA (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:125 V
- Actuator Type:Overtravel Plunger
- Mounting Type:Chassis Mount
- Termination Style:Screw Terminal
- Ingress Protection:-
- Features:-
- Operating Force:397 ~ 624gf
- Release Force:283gf
- Pretravel:0.050" (1.27mm)
- Differential Travel:0.002" (0.05mm)
- Overtravel:0.094" (2.4mm)
- Operating Temperature:-55°C ~ 85°C
