- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 25A 125V
- CategorySnap Action, Limit Switches
- Datasheet BA-3ST Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$26.985
- 50$26.985
Quote It
Technical Details
- Series:BA
- Package:Bulk
- Part Status:Active
- Circuit:SPDT (DB/DM)
- Switch Function:On-Mom
- Current Rating (Amps):25A (AC), 1A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:125 V
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Chassis Mount
- Termination Style:Screw Terminal
- Ingress Protection:-
- Features:-
- Operating Force:737 ~ 1077gf
- Release Force:283gf
- Pretravel:0.065" (1.65mm)
- Differential Travel:0.008" (0.2mm)
- Overtravel:0.010" (0.25mm)
- Operating Temperature:-55°C ~ 85°C
