- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 15A 125V
- CategorySnap Action, Limit Switches
- Datasheet BZE6-RNX1 Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$103.694
- 5$103.694
Quote It
Technical Details
- Series:E6
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-On
- Current Rating (Amps):15A (AC), 500mA (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:125 V
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Chassis Mount
- Termination Style:Screw Terminal
- Ingress Protection:IP66 - Dust Tight, Water Resistant
- Features:Actuator Seal Boot, Reset Plunger
- Operating Force:170 ~ 567gf
- Release Force:-
- Pretravel:0.078" (2.0mm)
- Differential Travel:-
- Overtravel:0.187" (4.75mm)
- Operating Temperature:-32°C ~ 71°C
