M2022SS2W13-BC
NKK Switches- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE DPDT 6A 125V
- CategoryToggle Switches
- Datasheet M2022SS2W13-BC Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$7.05
Quote It
Technical Details
- Series:M
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Circuit:DPDT
- Switch Function:On-On
- Current Rating (Amps):6A (AC), 4A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Standard Round with Cap
- Actuator Length:13.50mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:PC Pin
- Panel Cutout Dimensions:-
- Bushing Thread:Unthreaded
- Ingress Protection:-
- Features:Red Cap
- Operating Temperature:-30°C ~ 85°C
