M2012SD3A01
NKK Switches
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE SPDT 6A 125V
- CategoryToggle Switches
- Datasheet M2012SD3A01 Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$7.28
- 10$6.916
- 25$6.73422
- 50$6.552
- 100$6.37
- 250$6.006
- 500$5.096
- 1,000$4.823
Quote It
Technical Details
- Series:M
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount
- Circuit:SPDT
- Switch Function:On-On
- Current Rating (Amps):6A (AC), 4A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Standard Round
- Actuator Length:10.50mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Solder Lug
- Panel Cutout Dimensions:Circular - 6.50mm Dia
- Bushing Thread:1/4-40
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Features:Epoxy Sealed Terminals
- Operating Temperature:-30°C ~ 85°C
