1004P3T1B1M7QE
E-Switch- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE 4PDT 5A 120V
- CategoryToggle Switches
- Datasheet 1004P3T1B1M7QE Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$7.4679
- 200$7.4679
Quote It
Technical Details
- Series:100
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount, Right Angle, Vertical
- Circuit:4PDT
- Switch Function:On-Off-On
- Current Rating (Amps):5A (AC/DC)
- Voltage Rating - AC:120 V
- Voltage Rating - DC:28 V
- Actuator Type:Standard Round
- Actuator Length:10.41mm
- Illumination:Non-Illuminated
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:PC Pin
- Panel Cutout Dimensions:Circular - 6.35mm Dia
- Bushing Thread:1/4-40
- Ingress Protection:-
- Features:Epoxy Sealed Terminals
- Operating Temperature:-30°C ~ 85°C
